Material Forming Metal Machine Automatic Sheet Metal Feeder For Press Machine

Name: Material Forming Metal Machine Automatic Sheet Metal Feeder For Press Machine
Brand: RUIHUI
Price: 1 USD

Buy cheap Material Forming Metal Machine Automatic Sheet Metal Feeder For Press Machine product

Brand Name : RUIHUI

Certification : CE Certificate

Place of Origin : Guangdong, China (Mainland)

MOQ : 1 Set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30 Sets Per Month

Delivery Time : 30 work days

Packaging Details : Wooden Box or Vacuum Packing

Use : Sheet

Voltage : 380V/Customized

Power(W) : 6KW

Dimension(L*W*H) : 1400*1850*2070

Weight : 2.5T

Warranty : 1 Year

Product Name : NC Servo Straightener Feeder

Material Width : 50-300mm

Material Thickness : 0.2-3.0mm

Coil Weight : 2000kg

Work Roll Number : Upper 4 /down 3

Feed Roll Number : 1 set

Material : Metal

Power : 3 Phase 220V/380V/50HZ

Mandrel Expansion : hydraulic

Contact Now

Material Feeder, Forming Metal Machine, Nc Straightener Feeder, automatic sheet metal feeder for press machine

http://www.ruihui.net

Preventive advice for servo feeder feed inaccuracy
1. Whether the air pressure is unstable or not, you can check it out. This mainly refers to the air feeder. This has been highlighted above.
2. Is the feeder speed too fast? Generally speaking, the servo feeder is at most 150-200 in one minute. If you play too much, the feeder can't keep up, it is easy to cause the feed to be inaccurate.
3. Is there a problem with the mold? You can try to manually check the product to see if there is a problem with the mold.
4. Check if the MAC feeder has air leakage (depending on pneumatic relaxation or mechanical relaxation).
5. Relaxation is not good enough, that is to say, whether the cooperation between the punching cam and the feeder is synchronized. If you can't relax, try adjusting the punch cam or the feed box.

6. Whether the material is too oily, it is easy to cause the feeding to slip.
Material Forming Metal Machine Automatic Sheet Metal Feeder For Press Machine
Specification:

Model	MAC2-400	MAC2-500	MAC2-600		MAC2-800
Stock Width(mm)	50-400	50-500	50-600		50-800
Stock Thickness(mm)	0.3~3.2	0.3-3.2	0.3-3.2		-3.2
Max.Coil Weight(kg)	3000	3000	3000	5000	5000	7000
Max.Coil O.D.(mm)	1200	1200	1200
Coil I.D.(mm)	8	8	508		508
Feed Length(mm)	~500*	~500*	~500*		~500*
Max. Line Speed(m/min)	16-24	16-24	16-24		16-24
Work Roll Number(pieces)	upper 6 lower 5	upper 6 lower 5	upper 6 lower 5		upper 6 lower 5
Feed Roll Number(set)	1	1	1		1
Main Motor(kw)	AC2.9	AC2.9	AC4.4		AC4.4
Mandrel Expansion	hydraulic	hydraulic	hydraulic		hydraulic
Reel Motor(kw)	1.5	1.5	1.5	2.2	2.2	3.7
Power(V)	3 Phase 220V/380V/50HZ
Operating Air(Mpa)	0.49	0.49	0.49		0.49

Straigtening performance:

tock Thicknees (mm)	Stock Width (mm)
0.3	400	500	600	800
0.4
0.6
0.8
1.0
1.2
1.4
1.6			470	470
1.8			400	400
2.0			360	360
2.3	300	300	300	300
2.5	230	230	230	230
2.8	150	150	150	150
3.2	110	110	110	110

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Material Forming Metal Machine Automatic Sheet Metal Feeder For Press Machine

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
